Limit switch VP 15K-21A-231-54 U2.8 Elektrotehnik ET054533
SKU: ET054533
ETIM: EC000030
806 ₽
Get back 8 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
VP 15 series selector switches are designed for use in electrical control, signaling, and monitoring circuits of the relative position of moving parts of the mechanism in space. Main application - switching of AC control circuits up to 660 V at 50 and 60 Hz and DC voltage up to 440 V under the influence of control stops at certain points of the controlled object's path.
* Wide range of drive types;
* High degree of protection against moisture and dust;
* High switching wear resistance;
* Impact-resistant silumin housing.
Sensor height
131 мм
Sensor length
44 мм
Interface version
No (without)
Gas explosion protection category (EU ATEX directives)
No (without)
Dust explosion protection category (EU ATEX Directive)
No (without)
Number of normally closed (NC) contacts
1
Number of normally open (NO) contacts
1
Number of switching contacts
2
Housing material
Silumin (aluminium-silicon alloy)
Rated operational current Ie at AC-15, 230V
10 А
Suitable for security systems
Yes
Housing coating
Powder-coated
Ambient operating temperature to
50 град.C
Ambient operating temperature from
-45 град.C
Manual control
No
With status indication
No
IP protection rating
IP54
Connection type
MG-type cable gland
Control element type
Roller plunger
Sensor width
40 мм
