IEK
Limit Switch KV-8168 double spring rod IP65 IEK KKV12-8168-2-65
SKU: KKV12-8168-2-65
ETIM: EC000030
945 ₽
Get back 9 ₽ in points
Analogues by specifications
Stock by warehouse
K V IEK limit switches are designed for switching electrical control, signaling, and monitoring circuits with voltages up to 250 V under the action of moving parts of the mechanisms.
Comply with the requirements of TR CU 004/2011 and GOST IEC 609475-1.
Without self-return (with latching)
No
Control element alignment
Other
Sensor height
24.9 мм
Sensor diameter
Please provide the text you would like me to translate. мм
Sensor length
78.7 мм
Permissible switching frequency per hour
1800
Number of normally closed (NC) contacts
1
Number of normally open (NO) contacts
1
Number of switching contacts
1
Housing complies with standards
Other
Housing material
Metal
Housing material
Metal
Mech. endurance
1000000
Rated switching current Ie at AC-15 250V
3
Rated switching current Ie A at DC-13 14V
4
Rated switching current Ie A at DC-13 30 V
4
Rated operational current Ie at AC-15, 125 V
3 А
Rated operational current Ie at AC-15, 230V
Please provide the text you would like me to translate. А
Suitable for security systems
Yes
Direct stem stroke
30
Ambient operating temperature to
70 град.C
Ambient operating temperature from
-20...70 град.C
IP protection rating
IP65
Connection type
Other
Control element type
Flexible rod
Direct actuation force
1.5
Conventional thermal current Ith
10
Switching function
Momentary switch
Sensor width
28.6 мм
