Электротехник
Limit switch KU-703 U1 10A IP44 lever with weight 2 electrical circuits without counterweight Elektrotekhnik ET003119
SKU: ET003119
ETIM: EC000030
Price on request
Analogues by specifications
Stock by warehouse
KU and NV series limit switches are designed for switching control circuits in AC crane drives with voltage up to 500 V, frequency 50/60 Hz, and DC voltage up to 440 V, and are installed in control circuits to limit the linear movement of mechanisms. The switches have two independent electrical circuits and can operate on both AC and DC in intermittent mode.
* Wide selection of actuator types;
* High degree of protection against moisture and dust;
* High switching and mechanical wear resistance;
* Silumin housing;
* Simple device installation;
* High wear resistance indicators.
Without self-return (with latching)
Yes
Interface version
No (without)
Gas explosion protection category (EU ATEX directives)
No (without)
Dust explosion protection category (EU ATEX Directive)
No (without)
Number of normally closed (NC) contacts
2
Number of normally open (NO) contacts
2
Number of switching contacts
4
Number of safety-related auxiliary contacts
2
Housing material
Silumin (aluminium-silicon alloy)
Suitable for security systems
Yes
Housing coating
Powder-coated
Ambient operating temperature to
40 град.C
Ambient operating temperature from
-45 град.C
Manual control
Yes
With status indication
No
IP protection rating
IP44
Product/component type
Limit switch
Connection type
PG cable gland
Control element type
Angled roller lever
Electronic output
Yes
