Cam switch VP-15K21A211-54U2.3 1NO+1NC 10A IP54 (plastic actuator) semi-instantaneous action pusher A8014-79683078 PEO other
SKU: A8014-79683078
ETIM: EC000030
1,664 ₽
Get back 16 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Without self-return (with latching)
No
Sensor height
44 мм
Sensor length
106 мм
Interface version
No (without)
Number of normally closed (NC) contacts
1
Number of normally open (NO) contacts
1
Number of switching contacts
0
Number of safety-related auxiliary contacts
0
Housing material
Silumin (aluminium-silicon alloy)
Rated operational current Ie at AC-15, 125 V
10 А
Rated operational current Ie at AC-15, 230V
10 А
Rated operational current Ie at AC-15, 24 V
10 А
Rated operating current Ie at DC-13, 125 V
10 А
Rated operating current Ie at DC-13, 230 V
10 А
Rated operating current Ie at DC-13, 24 V
10 А
Suitable for security systems
No
Housing coating
Powder-coated
Ambient operating temperature to
45 град.C
Ambient operating temperature from
-60 град.C
Manual control
No
With status indication
No
IP protection rating
IP54
Product/component type
Limit switch
Connection type
PG cable gland
Control element type
Plunger
Sensor width
40 мм
Electronic output
No
