Cam switch VP-15K21B291-54U2.3 1NO+1NC 10A IP54 lever with roller adjustable length semi-instantaneous action A8014-80086067 PEO other
SKU: A8014-80086067
ETIM: EC000030
1,480 ₽
Get back 14 ₽ in points
Analogues by specifications
No description available
Without self-return (with latching)
Yes
Sensor height
69 мм
Interface version
No (without)
Gas explosion protection category (EU ATEX directives)
ATEX gas explosion protection category 3G
Dust explosion protection category (EU ATEX Directive)
ATEX dust explosion protection category 3D
Number of normally closed (NC) contacts
1
Number of normally open (NO) contacts
1
Number of switching contacts
0
Number of safety-related auxiliary contacts
0
Housing material
Metal
Rated operational current Ie at AC-15, 125 V
10 А
Rated operational current Ie at AC-15, 230V
10 А
Rated operational current Ie at AC-15, 24 V
10 А
Rated operating current Ie at DC-13, 125 V
10 А
Rated operating current Ie at DC-13, 230 V
10 А
Rated operating current Ie at DC-13, 24 V
10 А
Suitable for security systems
No
Housing coating
Powder-coated
Ambient operating temperature to
45 град.C
Ambient operating temperature from
-60 град.C
Manual control
No
With status indication
No
IP protection rating
IP54
Connection type
PG cable gland
Control element type
Adjustable roller lever
Sensor width
44 мм
Electronic output
No
