Switch-disconnector 4p 1000A VR-101 two directions tandem with visible break DEKraft 40174DEK
SKU: 40174DEK
ETIM: EC000216
179,523 ₽
Get back 1,795 ₽ in points
Analogues by specifications
VR-101 series switch-disconnector type WT Dekraft; 4P; reversing, type T (Tandem); with visible break; rated current 1000 A; frame size 1600; rated voltage up to 690 V, 50 Hz; application category - AC-22B (mixed active and inductive loads). Double contact break ensures reliable arc quenching and reduces the risk of damage. Power supply can be provided from both the top and bottom of the device. Copper terminals ensure high electrical conductivity and convenience of conductor connection.
Housing height
600 мм
Housing depth
365 мм
Version as switch-disconnector
Yes
Version as main switch
No
Number of auxiliary NO contacts
0
Number of auxiliary break contacts
0
Number of poles
4
Design
Built-in fixed-mounted device
Maximum rated operational voltage Ue AC
690 В
Motor drive optional
No
Independent trip unit
No
Rated insulation voltage Ui
800 В
Rated continuous current Iu
1000 А
Reversing design
Yes
With interlock
Yes
Ingress protection (IP) of front side
IP00
Main electrical circuit connection type
Screw connection
Control element type
Toggle switch
Conditional rated short-circuit current Iq
50 кА
Colour of control elements
Black
Housing width
320 мм
