DEKraft
4p 250A switch-disconnector VR-101 two-way symmetrical with visible break DEKraft 40265DEK
SKU: 40265DEK
ETIM: EC000216
33,709 ₽
Get back 337 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Switch-disconnector VR-101 series type WS Dekraft; 4P; reversing, type S (Symmetrical); with visible break; rated current 250 A; frame size 250; rated voltage up to 690 V, 50 Hz; application category - AC-22B (mixed resistive and inductive loads). Double contact break ensures reliable arc quenching and reduces the risk of damage. Power supply can be from either the top or the bottom of the device. Copper terminals ensure high electrical conductivity and ease of conductor connection.
Housing height
503 мм
Housing depth
153 мм
Version as switch-disconnector
Yes
Version as main switch
No
Number of auxiliary NO contacts
0
Number of auxiliary break contacts
0
Number of poles
4
Design
Built-in fixed-mounted device
Maximum rated operational voltage Ue AC
690 В
Motor drive optional
No
Independent trip unit
No
Rated insulation voltage Ui
800 В
Rated continuous current Iu
250 А
Reversing design
Yes
With interlock
Yes
Ingress protection (IP) of front side
IP00
Main electrical circuit connection type
Screw connection
Control element type
Toggle switch
Conditional rated short-circuit current Iq
12 кА
Colour of control elements
Black
Housing width
172 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
