Switch-disconnector 4p 3150A VR-101 two directions tandem DEKraft 40133DEK
SKU: 40133DEK
ETIM: EC000216
912,987 ₽
Get back 9,129 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
VR-101 series switch-disconnector Dekraft; 4P; reversing, type T (Tandem); rated current 3150 A; frame size 3150; rated voltage up to 690 V, 50 Hz; application category - AC-22B (mixed active and inductive loads). Double contact break ensures reliable arc quenching and reduces the risk of damage. Power supply can be connected from both the top and bottom of the device. Copper terminals provide high electrical conductivity and convenience for conductor connection.
Housing height
598 мм
Housing depth
540 мм
Version as switch-disconnector
Yes
Version as main switch
No
Number of auxiliary NO contacts
0
Number of auxiliary break contacts
0
Number of poles
4
Design
Built-in fixed-mounted device
Maximum rated operational voltage Ue AC
690 В
Motor drive optional
No
Independent trip unit
No
Rated insulation voltage Ui
800 В
Rated continuous current Iu
3150 А
Reversing design
Yes
With interlock
Yes
Ingress protection (IP) of front side
IP00
Main electrical circuit connection type
Screw connection
Control element type
Toggle switch
Conditional rated short-circuit current Iq
50 кА
Colour of control elements
Black
Housing width
492 мм
