Air circuit breaker 3p 1000A SystemePact ACB16NA withdrawable GP MCH+MX+XF AC 230V SE SPA16NA103DHNN54RU Systeme Electric

Air circuit breaker SystemePact ACB SD series is designed for use in low voltage networks up to 690 V (AC). The device is used for operational switching and load disconnection. Rated characteristics: Un (AC) = 400 V/690 V, In = 1000 A, 3P, Icw (AC-400 V) = 42 kA, Icw (AC-690 V) = 35 kA, Icm (AC-400 V) = 88 kA, Icm (AC-690 V) = 73 kA, version - withdrawable, connection - rear horizontal, built-in (AC-230 V): MCH motor drive, XF closing coil, MX shunt trip, PF ready-to-close contact (1 pc.), cradle position contacts: racked in/racked out/test (1 pc. each). Number of auxiliary state contacts - 4 pcs. Overall size: ACB-1. WxHxD NET (cm): 32.2x28.8x27.7. WxHxD GROSS (cm): 38x37x45. NET weight: 29 kg. GROSS weight: 36 kg.
