Molded Case Circuit Breaker 3p 3200/3200A 100kA VA-45 PROxima fixed EKF mccb45-3200-3200
SKU: mccb45-3200-3200
ETIM: EC000228
378,354 ₽
Get back 3,783 ₽ in points
Analogues by specifications
Stock by warehouse
VA-45 to 6300A series automatic circuit breakers are designed to carry current under normal conditions and disconnect overcurrents during short circuits and overloads (including single-phase ground faults) and are used in three-phase AC electrical networks with a voltage up to 690V and a frequency of 50 Hz. These circuit breakers are used as incoming automatic circuit breakers; for protecting electric motor circuits, as well as outgoing lines, including in Main Switchboards (MSB), Distribution Boards (DB); in automatic transfer switch schemes with sectioning (on three circuit breakers) and without sectioning (on circuit breakers); for protecting outgoing lines on the low side of 10/0.4 kV transformer substations.
Main circuit connection type
Rear connection
Built-in ground fault protection
Yes
Built-in motor drive
Yes
Short-time delayed short-circuit release range
1280...48000 А
Overload protection device setting range to
3200 А
Setting range of overload protection device from
1280...3200 А
Instantaneous short-circuit release setting range to
256000 А
Instantaneous short-circuit release setting range from
12800 А
Trip indicator present
Yes
Number of auxiliary NO contacts
0
Number of auxiliary changeover contacts
4
Number of auxiliary break contacts
0
Number of poles
3
Design
Built-in fixed-mounted device (stationary)
DIN rail mounting (O-type) optional
No
Motor drive optional
Yes
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
100 кА
Rated voltage up to
690 В
Rated voltage from
400...690 В
Rated continuous current Iu
3 200 А
Suitable for DIN-rail mounting
No
With minimum voltage protection
Yes
IP protection rating
IP30
Product/component type
Air circuit breaker
Main electrical circuit connection type
Bolted connection
Control element type
Push button
