Screw terminal block ZVI-20 2.5-14mm² 12 pairs NO-12W-20 polyethylene white Era B0051355
SKU: Б0051355
ETIM: EC001284
113 ₽
Get back 1 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Terminal clamp (ZVI) is used for screw connection of conductors, protecting the wire from damage and preventing short circuits to the electrical installation enclosure. Used in electrical circuits with a rated voltage of up to 400V and a frequency of 50 Hz. The connection is made using brass contacts. The cable or wire core is secured by a screw clamp. The insulating frame is made of transparent polyethylene or polypropylene. The terminal block can be easily cut into blocks with the required number of terminal pairs.
Number of terminals per pole
2
Number of poles
12
Housing insulation material
Polyethylene
Rated voltage
400 В
Rated current In
20 А
Connection position
Side
Flexible stranded conductor cross-section up to
14 кв.мм
Stranded flexible conductor cross-section from
2.5 кв.мм
Mounting method
Direct mounting
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Color
White
