EKF
Piercing tap connector N640 16-120 mm2 / 6-35 mm2 (bare wire / SIC) indiv. pack. EKF n-640-r
SKU: n-640-r
ETIM: EC001062
352 ₽
Get back 3 ₽ in points
Analogues by specifications
Stock by warehouse
N-640 type clamp is designed to create a watertight electrical connection between insulated SIP wire and uninsulated overhead line main wire. Contact with the insulated wire is ensured by piercing the insulation, and with the uninsulated wire – by a clamping plate. Upon reaching the torque required to create a reliable electrical contact between the wires, the bolt head shears off. Contact plates are made of aluminum alloy. Contact grease is applied to the piercing elements. The bolt is insulated from the clamp contact parts. The clamp is resistant to ultraviolet and solar radiation, high and low temperatures, corrosion, and aggressive atmospheric conditions.
Protective surface coating
Uncoated (bare)
Insulated clamp
Yes
Main conductor material
Aluminum
Branch conductor material
Aluminum
Nominal bore to
120 кв.мм
Nominal flow cross-section from
16...120 кв.мм
Rated branch cross-section to
35 кв.мм
Rated branch cross-section from
6...35 кв.мм
Main conductor cross-section from
16 кв.мм
Branch conductor cross-section from
6 кв.мм
Product/component type
Insulated clamp
Type of clamping channel for main conductor
Open on both sides
Branch conductor clamp channel type
Open on both sides
Connection type
Screw/bolt connection with insulation piercing (IPC)
