IEK
Insulated screw end terminal clamp KZVI 2.5mm2 (5x1) IEK UZVK-025-5
SKU: UZVK-025-5
ETIM: EC001284
2,560 ₽
Get back 25 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 40 шт
Analogues by specifications
Stock by warehouse
No description available
Version tested for explosion protection "Ex e"
No
Height
16.4 мм
Length
17.4 мм
Permissible continuous current
20
Climatic version
UKhL3.1
Number included
40
Number of terminals per pole
1
Number of poles
1
Max. operational voltage Ue
450
Maximum conductor cross-section
2x2.5 кв.мм
Clamping bracket material
Brass
Housing insulation material
Other
Tightening torque Nm at conductor cross-section
0.8
Rated AC operating voltage Ue
450
Rated DC operating voltage Ue
450
Rated frequency
50
Rated connection capacity
2x1.5...2x2.5
Rated voltage
450 В
Rated insulation voltage Ui
500 В
Rated current In
20 А
Closing plate can be fitted if required
No
Transparent
Yes
Operating temperature
85 град.C
Operating temperature from
-25...85 град.C
Connection position
Top
Flame propagating
No
Stranded flexible conductor cross-section from
2x2.5 кв.мм
Solid conductor cross-section from
2x2.5 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
2x2.5 кв.мм
Mounting method
Direct mounting
IP protection rating
IP20
Product/component type
ZVI terminal block
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Color
Other
Colour
Other
Width
9.8 мм
Width/connection pitch
9.8 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
