IEK
Screw contact clamp ZVI-15 n/g 4.0-10mm2 12pairs black IEK UZV5-015-06
SKU: UZV5-015-06
ETIM: EC001284
141 ₽
Get back 1 ₽ in points
Analogues by specifications
Stock by warehouse
The clamp is designed for screw connection of conductors, protecting the wire from damage and eliminating the possibility of a short circuit to the electrical installation enclosure. The insulation frame is made of white non-flammable polystyrene.
Height
17 мм
Height
17 мм
Length
138 мм
Length
138 мм
Permissible continuous current
15
Climatic version
UKhL3.1
Number of terminals per pole
2
Number of poles
12
Max. operational voltage Ue
400
Clamping bracket material
Brass
Housing insulation material
Polystyrene
Housing material
Polystyrene
Housing material
Polystyrene
Tightening torque Nm at conductor cross-section
1.2
Rated voltage
400 В
Rated insulation voltage Ui
450 В
Rated current In
15 А
Transparent
No
Operating temperature
110 град.C
Operating temperature from
-25...110 град.C
Connection position
Side (transverse)
Flame propagating
No
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
4...10 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
4.0...10 кв.мм
Mounting method
Direct mounting
IP protection rating
IP00
Product/component type
ZVI terminal block
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Color
Black
Colour
Black
Width
23 мм
Width/connection pitch
23.0 мм
