Spring terminal feed-through CX10 10mm2 gray ARMAFIX IEK AF-CT40-00-K03-010
SKU: AF-CT40-00-K03-010
ETIM: EC000897
151 ₽
Get back 1 ₽ in points
Analogues by specifications
Stock by warehouse
Spring terminal for conductors up to 10 mm2. The spring clamp ensures reliable conductor fixation.
Version tested for explosion protection "Ex e"
No
Minimum possible mounting height
49.3 мм
Length
72.40 мм
Number of terminals per level
2
Number of poles
1
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
1000 В
Rated current In
57 А
Closing plate can be fitted if required
Yes
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Top
Stranded wire cross-section with ferrule
0.2...10 мм²
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
0.2...10 кв.мм
Solid conductor cross-section to
10 кв.мм
Solid conductor cross-section from
0.2...10 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...10 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Color
Grey
Colour
Grey
Width/connection pitch
10.0 мм
