IEK
Spring terminal CX2.5 2.5mm² series ARMAFIX IEK AF-CT40-00-K03-002
SKU: AF-CT40-00-K03-002
ETIM: EC000897
5,500 ₽
Get back 55 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 100 шт
Analogues by specifications
Stock by warehouse
CX series spring terminals are equipped with clamps with a cell tension spring and are suitable for various types of conductors. The clamping force is constant, ensuring a reliable contact with the conductor. Spring terminals are ideally suited for both standard applications and conditions with high vibration loads - marine and rail transport
Version tested for explosion protection "Ex e"
No
Minimum possible mounting height
37.5 мм
Length
50.00 мм
Number of terminals per level
2
Number of poles
1
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
1000 В
Rated current In
24 А
Closing plate can be fitted if required
Yes
Operating temperature
85 град.C
Operating temperature from
-40...85 град.C
Connection position
Top
Stranded wire cross-section with ferrule
0.2...2.5 мм²
Flexible stranded conductor cross-section up to
2.5 кв.мм
Stranded flexible conductor cross-section from
0.2...2.5 кв.мм
Solid conductor cross-section to
4 кв.мм
Solid conductor cross-section from
0.2...4.0 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...2.5 кв.мм
Mounting method
DIN rail (standard) 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Color
Grey
Colour
Grey
Width/connection pitch
5.0 мм
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
69 ₽
ОВЕН Spring terminal block feed-through 2.5mm2 MTS-2.5RD red OVEN 88300
SKU: 88300
50 ₽
DKC Mini feed-through terminal, screw clamp, 2 connection points, 2.5 sq.mm, gray TUR-M-2.5 DKC
SKU: TUR-M-2.5
69 ₽
IEK End cover for terminal block CTS-MC 4 poles 4mm2 grey IEK YCT12-00-4-K03-004-ZGL
SKU: YCT12-00-4-K03-004-ZGL
596 ₽
DKC Distribution block with vert. adapter for 15/35mm wide rails, push-in clamp, 12 connection points 2.5 mm², grey DTP1-012-04SPUG-V DKC
