IEK
Circuit Breaker VA44-37 3P 400A 35kA IEK SVA4410-3-0400-35
SKU: SVA4410-3-0400-35
ETIM: EC000228
71,116 ₽
Get back 711 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 4 шт
Analogues by specifications
Stock by warehouse
No description available
Weight
2.900 kg
Main circuit connection type
Front connection
Built-in ground fault protection
No
Built-in motor drive
No
Height
180.0 mm
Depth
133.5 mm
Setting range of overload protection device from
4000 A
Instantaneous short-circuit release setting range from
- A
Design
Stationary
Climatic version
UKhL3
Number of auxiliary NO contacts
0
Number of auxiliary changeover contacts
0
Number of auxiliary break contacts
0
Number of poles
3
Design
Built-in expansion device
Mechanical endurance with maintenance
7000
Motor drive optional
No
Electronic release available
No
Rated impulse withstand voltage
8
Rated service short-circuit breaking capacity Ics
18
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
35 kA
Rated voltage
400 V
Rated insulation voltage Ui
750 V
Rated voltage up to
400 V
Rated voltage from
400...400 V
Rated current
400 A
Rated continuous current Iu
400 A
Suitable for DIN-rail mounting
No
Power loss
180 W
Power consumption
60 W
Power consumption
60 kW
With minimum voltage protection
Yes
Tripping system
Thermal, electromagnetic
IP protection rating
IP30
Operating temperature from
-30...50 °C
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Toggle switch
Mains supply frequency
50 Hz
Width
120.0 mm
Electrical endurance without maintenance at AC 440V
2000
