EKF
Residual current circuit breaker RCBO AVDT-63M 1P+N 18mm 40A characteristic C 100mA type A electronic 6kA PROXIMA EKF D636EA40C100
SKU: D636EA40C100
ETIM: EC000905
5,302 ₽
Get back 53 ₽ in points
Analogues by specifications
Compact residual current circuit breaker with overcurrent protection (RCBO) АВДТ-63М PROXIMA EKF is a device that combines the functions of a circuit breaker with an electronic RCD type AC in a compact housing one module wide. When the circuit breaker detects a leakage current (fault) to ground or an overcurrent (overload or short circuit) in the protected network section, the device trips, leading to the disconnection of the protected network. A special feature of EKF residual current circuit breakers with electronic RCD is the presence of a surge protection unit. Complies with GOST IEC 61009-1.
Mounting installation depth
74 мм
For flush mounting
Yes
False tripping protection
No
Overvoltage category
3
Current limiting class
3
Number of protected poles
1
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
6 кВ
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
40 А
Rated leakage current
0.1 мА
Total number of poles
2
Ambient operating temperature to
55 град.C
Ambient operating temperature from
-25...55 град.C
Current type
AC (alternating)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
0...16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
0...25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
Please provide the text you would like me to translate.
Resistance to current surges
6 кА
Tripping characteristic
Without delay
Tripping characteristic
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)
50 Hz
Width in modular units
1
