Residual current circuit breaker with overcurrent protection RCBO AVDT-63N 1P+N 10A characteristic C 30mA type A electronic 6kA PROXIMA EKF D63N26EA10C30

SKU: D63N26EA10C30 ETIM: EC000905

1,518 ₽

Get back 15 ₽ in points

Stock by warehouse

Manufacturer warehouse September 28 · Delivery to Smolensk Oblast on October 3 5 шт On order РЦ Тула September 28 · Delivery to Smolensk Oblast on October 3 55 шт On order РЦ Калуга September 30 · Delivery to Smolensk Oblast on October 5 83 шт On order РЦ Москва 2 September 30 · Delivery to Smolensk Oblast on October 5 7 шт On order

Description Specifications Reviews

Mounting installation depth 72 мм

For flush mounting Yes

False tripping protection No

Overvoltage category 3

Current limiting class 3

Number of protected poles 1

Rated breaking capacity per IEC 60947-2 6 кА

Rated short-circuit breaking capacity Icn per EN 61009-1 6 кА

Rated impulse voltage 6 кВ

Rated voltage 230 В

Rated insulation voltage Ui 500 В

Rated current 10 А

Rated leakage current 0.03 мА

Total number of poles 2

Ambient operating temperature to 50 град.C

Ambient operating temperature from -25...50 град.C

Current type AC (alternating)

With switched neutral conductor Yes

With interlock device No

Flexible stranded conductor cross-section up to 16 кв.мм

Stranded flexible conductor cross-section from 0...16 кв.мм

Solid conductor cross-section to 25 кв.мм

Solid conductor cross-section from 0...25 кв.мм

Pollution degree (number) 3

IP protection rating IP20

Residual current type Please provide the text you would like me to translate.

Resistance to current surges 6 кА

Tripping characteristic Without delay

Tripping characteristic It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.

Frequency (Hz) 50/60 Hz

Width in modular units 2
