RCBO AVDT-63N 1P+N 20A curve B 30mA type AC electronic 6kA PROXIMA EKF D63N26E20B30

SKU: D63N26E20B30

ETIM: EC000905

3259 ₽

Price list (incl. VAT): 3213 ₽

Available August 4

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
	Manufacturer warehouse Available	4	шт	August 4	August 4

Select a warehouse to order

Description Specifications Reviews

Mounting installation depth	72 мм
For flush mounting	Yes
False tripping protection	No
Overvoltage category	3
Current limiting class	3
Number of protected poles	1
Rated breaking capacity per IEC 60947-2	6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1	6 кА
Rated impulse voltage	6 кВ
Rated voltage	230 В
Rated insulation voltage Ui	500 В
Rated current	20 А
Rated leakage current	0.03 мА
Total number of poles	2
Ambient operating temperature to	50 град.C
Ambient operating temperature from	-25...50 град.C
Current type	AC (alternating)
With switched neutral conductor	Yes
With interlock device	No
Flexible stranded conductor cross-section up to	16 кв.мм
Stranded flexible conductor cross-section from	0...16 кв.мм
Solid conductor cross-section to	25 кв.мм
Solid conductor cross-section from	0...25 кв.мм
Pollution degree (number)	3
IP protection rating	IP20
Residual current type	AC (alternating)
Resistance to current surges	6 кА
Tripping characteristic	Without delay
Tripping characteristic	Please provide the text you would like me to translate.
Frequency (Hz)	50/60 Hz
Width in modular units	2
