RCBO AVDT-63N 1P+N 40A characteristic C 30mA type AC electronic 6kA PROXIMA EKF D63N26E40C30

SKU: D63N26E40C30

ETIM: EC000905

1463 ₽

Price list (incl. VAT): 2743 ₽

Available August 11

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
Manufacturer warehouse
	Manufacturer warehouse Available	1056	шт	August 11	clarifying
Remote warehouse
	Transit warehouse Available	51	шт	August 10	clarifying
	РЦ Тверь Available	100	шт	August 11	clarifying

Select a warehouse to order

Description Specifications Reviews

Mounting installation depth	72 мм
For flush mounting	Yes
False tripping protection	No
Overvoltage category	3
Current limiting class	3
Number of protected poles	1
Rated breaking capacity per IEC 60947-2	6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1	6 кА
Rated impulse voltage	6 кВ
Rated voltage	230 В
Rated insulation voltage Ui	500 В
Rated current	40 А
Rated leakage current	0.03 мА
Total number of poles	2
Ambient operating temperature to	50 град.C
Ambient operating temperature from	-25...50 град.C
Current type	AC (alternating)
With switched neutral conductor	Yes
With interlock device	No
Flexible stranded conductor cross-section up to	16 кв.мм
Stranded flexible conductor cross-section from	0...16 кв.мм
Solid conductor cross-section to	25 кв.мм
Solid conductor cross-section from	0...25 кв.мм
Pollution degree (number)	3
IP protection rating	IP20
Residual current type	AC (alternating)
Resistance to current surges	6 кА
Tripping characteristic	Without delay
Tripping characteristic	It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Frequency (Hz)	50/60 Hz
Width in modular units	2
