EKF
Circuit Breaker VA 47-29 2P 6A (C) 4.5kA BASIC mcb4729-2-06C EKF
SKU: mcb4729-2-06C
ETIM: EC000042
402 ₽
Price list (incl. VAT):
653 ₽
Available August 11
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
| Remote warehouse | |||||
|
Transit warehouse
Available
|
24 | шт | August 11 | clarifying | |
|
РЦ Тверь
Available
|
5 | шт | August 12 | clarifying | |
Select a warehouse to order
VA 47-29 4.5 kA EKF Basic circuit breakers are designed to provide facilities with reliable electrical equipment at an affordable price.
| Additional equipment possible | Yes |
| Mounting installation depth | 75 мм |
| For flush mounting | Yes |
| Overvoltage category | 3 |
| Current limiting class | 3 |
| Number of protected poles | 2 |
| Rated short-circuit breaking capacity Icu IEC 60898 at 230 V | 4.5 кА |
| Rated short-circuit breaking capacity Icu IEC 60898 at 400 V | 2.6 кА |
| Rated breaking capacity in accordance with EN 60898 | 4.5 кА |
| Rated impulse voltage | 4 кВ |
| Rated voltage | 230 В |
| Rated insulation voltage Ui | 660 В |
| Rated current | 6 А |
| Total number of poles | 2 |
| Ambient operating temperature to | 50 град.C |
| Ambient operating temperature from | -25...50 град.C |
| Current type | AC (alternating) |
| With switched neutral conductor | Yes |
| Flexible stranded conductor cross-section up to | 16 кв.мм |
| Stranded flexible conductor cross-section from | 1...16 кв.мм |
| Solid conductor cross-section to | 25 кв.мм |
| Solid conductor cross-section from | 1...25 кв.мм |
| Pollution degree (number) | 2 |
| IP protection rating | IP20 |
| Tripping characteristic | It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. |
| Frequency | 50 Гц |
| Frequency at | 50 Гц |
| Frequency from | 50...50 Гц |
| Width in modular units | 2 |
