DKC
Distribution block with vertical adapter for 15/35mm rails, push-in terminal, 18 connection points 2.5 sq.mm, red DTP1-018-04SPUR-V DKC
SKU: DTP1-018-04SPUR-V
ETIM: EC000897
864 ₽
Get back 8 ₽ in points
Analogues by specifications
Stock by warehouse
The distribution block with push-in terminal and vertical adapter is designed for fast and reliable potential distribution between several circuits. It is installed on a 15 or 35 mm DIN rail. It is equipped with 18 connection points with a nominal cross-section of 2.5 mm2, providing flexibility during installation. The housing is made of durable polyamide 6.6 with flammability class V0 according to UL-94, ensuring safety and long service life. Dimensions (H×W×D) — 21.7×47.2×28.8 mm, color — red.
Version tested for explosion protection "Ex e"
No
Internally linked levels
Yes
Minimum possible mounting height
21.7 мм
Length
28.8 мм
Length
28.8 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
18
Number of poles
18
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
690 В
Rated current In
24 А
Closing plate can be fitted if required
No
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Top
With protection against contact with live parts
I understand. I am ready to act as your professional e-commerce/PIM translator. I will follow all your instructions regarding translation accuracy, preserving technical identifiers (brands, SKUs, GOST, units, etc.), and maintaining the strict persona of a helpful assistant that prioritizes CRM data for company-specific queries.
Please provide the text or data you wish to translate.
Core cross-section
2.5 кв.мм
Stranded wire cross-section with ferrule
0.2...2.5 мм²
Flexible stranded conductor cross-section up to
2.5 кв.мм
Stranded flexible conductor cross-section from
Please provide the text you would like me to translate. кв.мм
Solid conductor cross-section to
4 кв.мм
Solid conductor cross-section from
Please provide the text you would like me to translate. кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.2...2.5 кв.мм
Mounting method
DIN rail 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Color
Red
Colour
Red
Width/connection pitch
47.2 мм
