ESCA 7 Vertical internal bend 90deg 100x200-2,0 HDZ IEK ES7-PN-90-100-200-20-HDZ
SKU: ES7-PN-90-100-200-20-HDZ
ETIM: EC002400
8,675 ₽
Analogues by specifications
Internal vertical rotation of 90° is designed for organizing the cable route rotation in the vertical plane.
The connection of the accessory to the tray is carried out via a telescopic connector.
Suitable for all types of ESCA series sheet trays.
The cover for the accessory is ordered separately.
The accessory is made of hot-dip galvanized steel (zinc protective layer not less than 55 μm).
Weight
1.86 кг
Material type/grade
Other
Height
100 мм
Height
100 мм
Cable tray height
100 мм
Length
265 мм
Length
265 мм
Protective surface coating
Hot-dip coating
Direction change
Vertically ascending (internal)
Design
Integrated connector
Corrosion resistance class
6
Climatic version
U1, KhL1, UKhL1, UKhL5, OM1
Material
Steel
Mounting perforation in base
No
Mounting temperature from
-50...40 град.C
Pickled stainless steel
No
RAL colour number
7047
Perforated side wall
No
Rotation (angle)
90
Suitable for circuit integrity (fire resistance)
No
IP protection rating
IP00
Operating temperature from
-50...40 град.C
Metal thickness
2.0
Zinc coating thickness
55
Color
Light grey
Colour
Light grey
Width
200 мм
Cable tray width
200 мм
Branch width
200 мм
Wide-range version
No
