EKF
IR ceiling motion sensor 1200W 360° up to 6m IP20 MS-20B EKF PROxima dd-ms-20B
SKU: dd-ms-20B
ETIM: EC000133
739 ₽
Get back 7 ₽ in points
Analogues by specifications
Stock by warehouse
Infrared motion sensor MS-20B is designed to save electricity through automatic control of lighting and other engineering systems. The sensor responds to the movement of people and other objects within the sensor's range; the sensor's operating principle is based on monitoring the level of IR radiation in the field of view.
The MS-20B sensor is designed for surface mounting on the ceiling. It is recommended to use the sensor in pantries, dressing rooms, and other rooms with temporary human presence.
Operating algorithm: when movement occurs in the sensor's field of view, the built-in electromechanical relay (rated for a full power of 1200W) switches the connected load. After that, the load remains energized for a set period (from 10 sec. to 7 minutes, adjustable) and then turns off. Additionally, the sensor has a light level control function. If the illumination in the detection zone is above the set level (adjustable), the load will not turn on, allowing for additional electricity savings.
C-load
No
HVAC or climate control
No
RAL number (similar)
9 010
Antibacterial
No
Material type/grade
Thermoplastic
Network connection capability
Yes
Height
60 мм
Height
60 мм
Diameter
118 мм
Diameter of detection area on floor
6 м
Remote control
No
Additional input
No
Switch-on delay
10 с
Switch-off delay
7 с
Anti-slip protection
No
Protective surface coating
Untreated
Animal detection zone
No
Design
Motion sensor
Max duty cycle
7 мин
Max switching power (connected load)
1 200 Вт
Maximum lateral range
6 м
Maximum frontal range
6 м
Maximum duty cycle
10 с
Material
Plastic
Halogen-free
Yes
Rated voltage
230 В
Optimal mounting height
3 м
Suitable for wireless transmission
No
Suitable for ceiling fastening
Yes
Suitable for wall mounting
No
Illuminance switching threshold
5...2000 лк
Constant illuminance control
Yes
Forced switch-on
Yes
Forced shutdown
No
Transparent
No
Adjustable trip illuminance
Yes
Current type
AC (alternating)
With remote control
No
With DALI interface
No
With signalling device
No
Mounting method
Surface mounting
Connection method
Screw connection
IP protection rating
IP20
Stepped monitoring
No
Temperature from
-10...40 град.C
Sensor type
Passive infrared (PIR)
Sensor type
Passive infrared (PIR)
Horizontal viewing angle up to
360 град.
Horizontal viewing angle from
360 град.
Scanning angle
360 град.
Configurable trip threshold
Yes
Alarm functions
No
Dimming function with dimmer mechanism
No
Optimal brightness detection function
No
Color
White
Colour
White
Frequency at
50 Гц
Frequency from
50...50 Гц
Width
118 мм
Shunt switch
No
