ITK (группа IEK)
ITK U/UTP Cat.6 twisted pair 4x2x23AWG solid LSZH ng(A)-HF orange (305m) LC1-C604-127
SKU: LC1-C604-127
ETIM: EC003249
33,766 ₽
Get back 337 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
No description available
Cable outer diameter
7.5±0.2
Wave impedance
100 Ω
Conductor diameter
.55 mm
Cable length
305 m
For laying in the ground
No
Permissible operating temperature (no movement) to
70 °C
Permissible operating temperature (without movement) from
-60 °C
NVP value
69 %
Core insulation
Solid polyethylene
Category
6
Conductor class
1 - single-wire
Reaction to fire class in accordance with EN 13501-6
P1b.8.1.2.1
Number of cores
8
Number of twisted elements
4
Max mutual capacitance per 100 metres
5.6
Max. contact resistance
20
Max. capacitance unbalance pF per 100 m
160
Max DC resistance per 100m at 20°C, not more than
9.38
Cable/wire grade
U/UTP
Core marking
Colour
Outer sheath material
Other
Conductor material
Copper
Mounting temperature from
-10...50 °C
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
Yes
Rated transmission rate
69
Rated voltage from
≤ 48 V
Rated conductor cross-section
.24 mm²
With metal cable
No
Halogen-free (per IEC 60754-2)
Yes
Core cross-section
23 mm
Insulation resistance
5000
Operating temperature from
-60...70 °C
Twist type
Layered
UV resistance
No
Outer sheath colour
Orange
Signal frequency
250
Screen over the twist
No (without)
Screen over stranding element
No (without)
Dielectric strength
1000
Twisting element
Paired
