Analogues by specifications
The cable is intended for the installation of communication and signaling systems, telecommunications, control, and data acquisition for single stationary and non-stationary laying in collectors, tunnels, buildings, and premises in the absence of mechanical stress on the cable.
The cable is operated at a voltage of up to 145 V AC in the frequency range up to 50 Hz or 200 V DC.
The cable is manufactured according to TU 27.32.13-006-39644825-2020 and meets safety requirements in accordance with GOST 31565-2012.
2 single-wire current-carrying conductors with a diameter of 0.5 mm are made of copper and have undergone 100% annealing, which makes the cable softer, simplifying the installation process and increasing service life.
A longitudinal shield made of laminated aluminum foil with a contact conductor is applied over the conductors.
The conductors and the shield are insulated with high-pressure polyethylene.
A polyvinyl chloride compound sheath is applied over these layers, allowing the wire to be operated in low and high temperature conditions.
Armoured
No
Conductor diameter
.5 мм
For laying in the ground
No
Permissible operating temperature (no movement) to
60 град.C
Permissible operating temperature (without movement) from
-35 град.C
Core insulation
Polyethylene (PE)
Insulation per GOST R IEC 60331
No
Category
No (without)
Conductor class
1 - single-wire
Number of cores
2
Core marking
Digits
Oil-resistant
No
Oil-resistant (in accordance with IEC 60811-404)
No
Outer sheath material
Polyvinyl chloride (PVC)
Conductor material
Copper
Outer diameter (approx.)
3.1 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated conductor cross-section
.2 кв.мм
Fire resistance
In accordance with IEC 60332-3-22
Main insulation
Polyethylene (PE)
Longitudinal water blocking
No
Radial water blocking
No
Recommended installation temperature during pulling, up to
60 град.C
Recommended installation temperature during pulling from
-10 град.C
With low smoke emission in accordance with IEC 61034-2
No
Halogen-free (per EN 60754-1/2)
No
Halogen-free (per IEC 60754-2)
No
Twist type
Bundled
UV resistance
No
Outer sheath colour
White
Screen over the twist
Foil
Screen over stranding element
Foil
Twisting element
No
