Flat terminal fully insulated (VF 1.25-187(8) A) (pack 100pcs) Rexant 08-0611

Fully insulated flat terminal (KPPY gn - 5 mm) 0.5-1.5 mm2 REXANT is designed to create a high-quality connection for electrical equipment or to connect wires together, which can be disconnected without extra effort if necessary. Such a terminal is used for crimping multi-strand copper wires during the installation of mobile electrical contact connections in rolling stock (automotive, railway, aircraft, and shipbuilding) or in other places where connection reliability is important (for example, telephone or climate equipment). Fully insulated flat terminal REXANT consists of two components: a metal connector (socket) and a protective insulator that completely covers the plug. The metal connector is made of brass with surface electrolytic tinning, and the terminal insulator is made of polyvinyl chloride (PVC), which reliably protects the cable crimp area and the contact part. Insulator color is red. Crimping is performed with special crimping pliers (ht-301) over the protective insulator. Each terminal has a lock-type fastener for a more secure mechanical connection with the plug connector. Main characteristics: Temperature range: -10...+75 °C Wire cross-section range: 0.5-1.5 mm2 Working plug width: B = 5.6 mm Maximum allowable current: 10 A The use of KPPY makes it possible to significantly speed up electrical installation work, while providing the possibility of repeated disconnection and reconnection of wires.
