Feed-through terminal, push-in clamp, 4 connection points, 2.5 sq.mm, grey VPR-2.5-QUATTRO-GY DKC

SKU: VPR-2.5-QUATTRO-GY ETIM: EC000897

129 ₽

Get back 1 ₽ in points

Stock by warehouse

Manufacturer warehouse August 19 · Delivery to Smolensk Oblast on August 24 57800 шт On order РЦ Калуга August 21 · Delivery to Smolensk Oblast on August 28 1204 шт On order

Description Specifications Reviews

Version tested for explosion protection "Ex e" No

Internally linked levels No

Minimum possible mounting height 37.2 мм

Length 73 мм

Flammability class of insulation material in accordance with UL57 V0

Number of terminals per level 4

Number of poles 4

Number of levels 1

Housing insulation material Thermoplastic

Rated voltage 800 В

Rated current In 24 А

Closing plate can be fitted if required Yes

Operating temperature 105 град.C

Operating temperature from -40 град.C

Connection position Top

Core cross-section 2.5 кв.мм

Stranded wire cross-section with ferrule 0.14...2.5 мм²

Flexible stranded conductor cross-section up to 2.5 кв.мм

Stranded flexible conductor cross-section from Please provide the text you would like me to translate. You only provided ".14", which does not contain meaningful text for translation. кв.мм

Solid conductor cross-section to 4 кв.мм

Solid conductor cross-section from Please provide the text you would like me to translate. You only provided ".14", which does not contain meaningful text for translation. кв.мм

Extra-fine-stranded flexible conductor cross-section without ferrule, from 0.14...2.5 кв.мм

Mounting method DIN rail 35 mm

Electrical connection type 1 Spring clamp connection

Electrical connection type 2 Spring clamp connection

Colour Grey

Color Grey

Width/connection pitch 5.2 мм
