Spring terminal KPI 2v-2.5 31A black IEK YZN11-002-K02

SKU: YZN11-002-K02

ETIM: EC001284

53 ₽

Price list (incl. VAT): 86 ₽

Available August 19

Order multiple: 50

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
	Manufacturer warehouse Available	1250	шт	August 19	August 19

Select a warehouse to order

Description Specifications Reviews

Length	49.30 мм
Length	49.30 мм
Design	Phase
Flammability class of insulation material in accordance with UL57	V0
Number of terminals per level	2
Number of poles	1
Number of levels	1
Housing insulation material	Other
Housing material	Polyamide 6.6
Housing material	Polyamide 6.6
Availability of PEN terminal	No
Rated voltage	800 В
Rated current In	31.0 А
Closing plate can be fitted if required	Yes
Operating temperature	85 град.C
Operating temperature from	-40...85 град.C
Connection position	Side (transverse)
Flexible stranded conductor cross-section up to	2.5 кв.мм
Stranded flexible conductor cross-section from	0.2...2.5 кв.мм
Solid conductor cross-section to	4 кв.мм
Solid conductor cross-section from	0.2...4 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from	2.5 кв.мм
Mounting method	DIN rail (standard) 35 mm
Electrical connection type 1	Spring clamp connection
Electrical connection type 2	Spring clamp connection
Color	Black
Colour	Black
Width/connection pitch	5.2 мм
