Terminal with disconnect, push-in clamp, 2 connection points, 4 sq.mm, grey VPR-4-TG DKC
SKU: VPR-4-TG
ETIM: EC000902
30,400 ₽
Get back 304 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 100 шт
Analogues by specifications
Stock by warehouse
TG disconnect terminal without disconnector blade with Push-in connection is designed for connecting two conductors, mounting component inserts, breaking the circuit, and safe maintenance and modification of a de-energized circuit. Top wire entry. Mounting on OMEGA DIN rail. Operating temperature from -40 to +105°C. Housing is made of PA 6.6 with flammability class V0 UL-94.
Grey color, 2 connection points, 4 mm2. 2 channels for pluggable jumpers. Dimensions (H*W*D) 41.7*60.7*6.2 mm.
Internally linked levels
No
Minimum possible mounting height
41.7 мм
Length
60.7 мм
Length
60.7 мм
Cross blade design
Plug-in
Longitudinal blade design
Rotary
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of levels
1
Housing insulation material
Thermoplastic
Rated voltage
500 В
Rated current In
20 А
Closing plate can be fitted if required
Yes
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Top
Stranded wire cross-section with ferrule
0.25...4 мм²
Flexible stranded conductor cross-section up to
4 кв.мм
Stranded flexible conductor cross-section from
.2 кв.мм
Solid conductor cross-section to
6 кв.мм
Solid conductor cross-section from
.2 кв.мм
Cross-section of extra-fine-stranded flexible conductor without ferrule to
4 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
.2 кв.мм
With built-in test socket
No
Mounting method
DIN rail 35 mm
Electrical connection type 1
Spring clamp connection
Electrical connection type 2
Spring clamp connection
Colour
Grey
Color
Grey
Width/connection pitch
6.2 мм
