Power distribution terminal block KVS 16-95mm2 2-row Rexant 11-2115

The KVS series power terminal block is used for connecting conductors and overhead insulated wire (SIP) when forming input systems, as well as for distributing wires inside electrical cabinets and switchboards. The device is applied as a transition node for connecting copper and aluminum cables. It is often used as an additional element during the setup and installation of industrial equipment. The terminal housing is made of high-quality non-flammable polyamide. The device is equipped with hex socket screws, ensuring reliable fixation of conductors. If necessary, the terminal can be easily and conveniently installed on a DIN rail or a mounting panel. Technical characteristics: Mounting method: DIN rail/screw Color: gray Number of poles: 2 Housing material: Polyamide (PA) Voltage: 1000 V Rated current: Cu 245 / Al 220 A Rated cross-section: 95 mm2 Rated connection capacity: 16-95 mm2 Tightening torque: 20 Nm Operating temperature: - 40...+85 °C Protection degree: IP20
