DKC
Grounding terminal, screw clamp, 2 connection points, 10 sq.mm TUR-10-PE DKC
SKU: TUR-10-PE
ETIM: EC000901
334 ₽
Get back 3 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
Screw terminal for grounding is designed for connecting two conductors. Mounting on OMEGA DIN rail. Operating temperature from -40 to +105°C. Housing made of PA 6.6 with flammability class V0 UL-94. Has electrical contact with the DIN rail.
Yellow-green color, 2 connection points, 10 mm2. 1 channel for plug-in jumpers. Dimensions (H×W×D) 47.5×53×10.2 mm.
Minimum possible mounting height
47.5 мм
Length
53 мм
Length
53 мм
Flammability class of insulation material in accordance with UL57
V0
Number of terminals per level
2
Number of levels
1
Housing insulation material
Thermoplastic
Availability of PEN terminal
false
Closing plate can be fitted if required
Yes
Operating temperature
105 град.C
Operating temperature from
-40 град.C
Connection position
Sideways
Stranded wire cross-section with ferrule
0.5...10 мм²
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
.5 кв.мм
Solid conductor cross-section to
16 кв.мм
Solid conductor cross-section from
.5 кв.мм
Extra-fine-stranded flexible conductor cross-section without ferrule, from
0.5...16 кв.мм
Mounting method
DIN rail 35 mm
Electrical connection type 1
Screw connection
Electrical connection type 2
Screw connection
Color
Yellow-green
Colour
Green/yellow
Width/connection pitch
10.2 мм
