Terminal block KE10.1 (AL 10-35/Cu 1.5-25) 88974 KVT

• Designed for connecting and branching aluminum and copper conductors inside enclosures or panels in poles and masts of outdoor lighting, as well as during the installation of self-supporting insulated wires (SIP) • Core cross-section: • AL 10-35 mm2 • Cu 1.5-25 mm2 • Contact part material: aluminum alloy • Clamping bolt material: anodized steel • Insulating housing material: polycarbonate • Operating voltage: up to 1 kV • The transparent insulating housing provides visual control both during installation and throughout the entire period of operation • The housing is non-detachable, which guarantees the insulation of the contact connection • The presence of special anti-corrosion paste on the contact part ensures guaranteed contact for both aluminum and copper cable cores • Cable core fastening is carried out by clamping using internal hex screws • The tightening torque of the contact part is 10 Nm • Complies with the requirements of GOST 30011.7.1 (IEC 60947-7-1) • Operating temperature range: -60 °C to +55 °C • Installation tool: 5 mm Allen key
