Support structure for horizontal rectangular air ducts and metal cable tray systems TECHNORAPTOR FOOT 500x1000 KM-TR-F-SSHRAD-500-1000 KM TR0087 KM SYSTEM

The specified dimensions are maximum. The frame is adjustable depending on the connection dimensions of the installed equipment. Before ordering components, it is required to calculate the snow and wind load for the specific delivery object. It is prohibited to fasten roof supports to the base. Fastening elements of the unit (bolts, nuts, vibration dampers, etc.) are not included in the specification of the support structure; the quantity and dimensions depend on the specific equipment. The KM-TECHNORAPTOR-FOOT roof support provides compensation for roof slope up to 8 degrees. Maximum allowable distributed load on the metal frame is 200 kg. This structure is made of steel strat-profile with a galvanized coating applied by the Sendzimir method. Execution with a hot-dip galvanized profile coating is also possible.
