Contactor KME compact 32A 220V 1NC EKF PROxima ctr-s-32-220-nc
SKU: ctr-s-32-220-nc
ETIM: EC000066
2143 ₽
Price list (incl. VAT):
3136 ₽
Preorder
No description available
| Number of auxiliary NO contacts | 0 |
| Number of auxiliary break contacts | 1 |
| Number of main NO contacts | 3 |
| Number of main NC contacts | 0 |
| Modular design | No |
| Rated switching power at AC-4, 400 V | 6 кВт |
| Rated operational current Ie at AC-4, 400 V | 12 А |
| Rated power at AC-3, 400 V | 15 кВт |
| Rated operational power (NEMA) | 8 кВт |
| Rated control supply voltage Us AC at 50 Hz up to | 253 В |
| Rated control supply voltage Us AC at 50 Hz from | 195.5...253 В |
| Rated control supply voltage Us DC up to | 0 В |
| Rated control supply voltage Us DC from | 0 В |
| Rated operational current Ie at AC-1, 400 V | 55 А |
| Rated operating current Ie at AC-3, 400 V | 32 А |
| Switch-on current type | AC (alternating) |
| Main electrical circuit connection type | Screw connection |
