EKF
Socket mechanism, 16A, without grounding, with shutters, black Epika EKF UP1-SOB-101
SKU: UP1-SOB-101
ETIM: EC000125
263 ₽
Price list (incl. VAT):
493 ₽
Available August 3
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
|
Manufacturer warehouse
Available
|
2672 | шт | August 3 | August 3 |
Select a warehouse to order
Single-gang EKF "Epica" collection socket without grounding and with shutters is a reliable and stylish solution for connecting electrical appliances.
Protective shutters on the contacts prevent accidental contact with live parts, ensuring the safety of children and pets.
The housing is made of durable plastic resistant to UV exposure, which guarantees durability and preservation of appearance.
The product is compatible with copper and aluminum cables and has screw terminals. The screws have the same slot, so no bit change is required during installation.
Soft-Touch coating provides pleasant tactile sensations due to the velvety matte surface, and also protects against scratches, fingerprints, and fading, maintaining an aesthetic appearance for a long time.
For harmonious interior design, it is recommended to use with a frame from the same collection.
| Special power supply | No special power supply required |
| RAL number (similar) | 9 005 |
| Material type/grade | Thermoplastic |
| Device height | 71 мм |
| Device depth | 35.1 мм |
| Differential current protection | No |
| For heavy duty (per VDE) | No |
| Contact protection | No |
| Overvoltage protection | No |
| Protective surface coating | Untreated |
| Round protective grounding contact (pin) | No |
| Insulated installation | Yes |
| Design | Without earthing contact |
| Number of seats | 1 |
| Number of phases | 1 |
| Material | Plastic |
| Extraction mechanism | No |
| Minimum depth of recessed mounting box | 35.1 мм |
| Cable trunking installation | No |
| Halogen-free | Yes |
| Rated voltage | 230 В |
| Rated current | 16 А |
| Support ring | Yes |
| Labelling surface | No |
| Suitable for ingress protection IP | IP20 |
| Transparent | No |
| With built-in USB charger | No |
| With power switch | No |
| With lock | No |
| With orientation lighting | No |
| With hinged cover | No |
| With illumination (mains voltage indication) | No |
| With signal lamp | No |
| With low-current fuse | No |
| With through-channel function | No |
| With central insert | No |
| Symbols/indication | Without marking/printing |
| With shutters (touch protection) | Yes |
| Mounting method | Internal / concealed |
| Connection method | Screw clamp/terminal |
| Configuration type | Mechanism with cover plate |
| Fastening type | By expansion (tabs) and screws |
| Surface type | Matte |
| Impact resistance | IK01 |
| Colour | Black |
| Color | Black |
| Frequency at | 60 Гц |
| Frequency from | 50...60 Гц |
| Device width | 71 мм |
