Generica (Группа IEK)
Switch ALC_LR-22 black 3 positions I-O-II NO+NC GENERICA BSW10-ALCLR-3-K02
SKU: BSW10-ALCLR-3-K02
ETIM: EC002611
357 ₽
Price list (incl. VAT):
476 ₽
Available August 26
Order multiple: 10 шт
Availability
| Warehouse | Qty | Unit | Ready for pickup | Delivery to Smolensk | |
|---|---|---|---|---|---|
| Manufacturer warehouse | |||||
|
Manufacturer warehouse
Available
|
610 | шт | August 26 | clarifying | |
| Remote warehouse | |||||
|
Transit warehouse
Available
|
2 | шт | August 10 | clarifying | |
|
РЦ Тверь
Available
|
131 | шт | August 11 | clarifying | |
Select a warehouse to order
No description available
| Height | 50.0 мм |
| Height | 50.0 мм |
| Depth | 87.0 мм |
| Hole diameter | 22.0 мм |
| Hole diameter | 22.0 мм |
| Electric shock protection class | Please provide the text you would like me to translate. I am ready to translate your product data from Russian to English following all your specified rules. |
| Number of auxiliary NO contacts | 1 |
| Number of auxiliary break contacts | 1 |
| Number of switch positions | 3 |
| Number of poles | 1 |
| Complete device in housing | No |
| Design | Built-in device |
| Maximum rated operational voltage Ue AC | 660 В |
| Rated AC operating voltage of contacts | 110; 230; 400; 660 |
| Nominal operating voltage of DC contacts | 24; 48; 110; 220; 440 |
| Rated operating current Ie at AC-15 400 V | 4.5 |
| Rated thermal current Ith | 10 |
| Rated connection capacity | 2x2.5 |
| Rated insulation voltage Ui | 660 В |
| Rated DC voltage from | 440 В |
| Rated operational current Ie at AC-15, 230V | 7.5 А |
| Rated continuous current Iu | 7.5 А |
| Position designation | 1-0-2 |
| Suitable for front panel mounting | No |
| Suitable for base mounting | No |
| Suitable for intermediate mounting | Yes |
| Suitable for distribution board | Yes |
| With return to zero position | No |
| With zero position | Yes |
| Ingress protection (IP) of front side | IP40 |
| Ingress protection (IP) - contact side | IP00 |
| Operating temperature from | -10...40 град.C |
| Switch type | Multi-step selector switch |
| Switch type | Multi-step selector switch |
| Product/component type | Cam switch |
| Main electrical circuit connection type | Screw connection |
| Handle type - additional devices | Short handle |
| Control element type | Short rotary handle (narrow grip) |
| Switch position latching | Yes |
| Switching function | Multi-step selector switch |
| Color | Black |
| Colour | Black |
| Width | 30.0 мм |
| Electrical endurance | 0.3 |
