IEK

Cam switch in enclosure closed handle 16A circuit 10 IEK MI-CS21-016-010

SKU: MI-CS21-016-010

ETIM: EC002611

2330 ₽

Price list (incl. VAT): 2647 ₽

Available August 20

Order multiple: 40

Availability

	Warehouse	Qty	Unit	Ready for pickup	Delivery to Smolensk
	Manufacturer warehouse Available	37	шт	August 20	August 20

Select a warehouse to order

Description Specifications Reviews

Design as auxiliary/maintenance switch	Yes
Version as main switch	Yes
Number of auxiliary NO contacts	0
Number of auxiliary break contacts	0
Number of switch positions	2
Number of poles	3
Complete device in housing	Yes
Design	Surface-mounted device
Maximum rated operational voltage Ue AC	690 В
Mech. endurance	0.3
Modular design	No
Circuit diagram number	10
Rated impulse withstand voltage	4
Rated power at AC-23 230V	4
Rated power at AC-23 400 V	7
Rated power at AC-3 230 V	3
Rated power at AC-3 400 V	5
Rated AC operating voltage of contacts	230; 400; 690
Nominal operating voltage of DC contacts	24; 48; 110; 220
Rated operational current Ie at AC-2 230 V	11
Rated operational current Ie at AC-2 400 V	11
Rated operational current Ie at AC-21 AC-22 230 V	16
Rated operating current Ie at AC-21 AC-22 400 V	16
Rated operational current Ie at AC-23 230 V	13
Rated operating current Ie at AC-23 400V	13
Rated operating current Ie at AC-3 230 V	3.5
Rated operating current Ie at AC-3 400V	3.5
Rated operating current Ie at AC-4 230 V	5
Rated operational current Ie at AC-4 400 V	4
Rated thermal current Ith	16
Rated conditional short-circuit current Icn	6
Rated connection capacity	2.5
Rated voltage	690 В
Rated insulation voltage Ui	690 В
Rated DC voltage from	24; 48; 110; 220 В
Rated continuous current Iu	16.0 А
Position designation	OFF-ON
Suitable for front panel mounting	No
Suitable for base mounting	No
Suitable for intermediate mounting	Yes
Suitable for distribution board	No
Front panel size	Other
With control unit	No
With return to zero position	No
With zero position	Yes
Stranded flexible conductor cross-section from	1…2.5 кв.мм
Ingress protection (IP) of front side	IP65
Ingress protection (IP) in enclosure	IP65
Ingress protection (IP) - contact side	IP00
IP protection rating	IP65
Operating temperature from	-5…40 град.C
Switch type	ON/OFF switch
Switch type	ON/OFF switch
Product/component type	Cam switch
Design type	In the housing
Main electrical circuit connection type	Screw connection
Control element type	Rotary position knob (latching)
Fuse current qG	20
Switch position latching	Yes
Switching function	Multi-step selector switch
Color	Black
Colour	Black
Electrical endurance	0.0015
