ONI (Группа IEK)
Frequency converter FC-431 380V 3Ph 45-55kW 90-110A built-in braking module ONI FC-431-33-45G55PT
SKU: FC-431-33-45G55PT
ETIM: EC001857
4,455,120 ₽
Get back 44,551 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 20 шт
Analogues by specifications
Stock by warehouse
No description available
Input current HD constant load mode
90
Input current, ND variable load mode
105
Height
390 mm
Height
390 mm
Output power at rated output voltage
55.00 kW
Output current, HD mode constant load
90.0
ND mode output current at variable load
110.0
Depth
196 mm
Electric shock protection class
I
Number of input phases
3
Number of output phases
3
Number of phases
3
Max. motor power in HD constant load mode
45
Max. motor power in ND variable load mode
55
Maximum output power at linear load at rated output voltage
45 kW
Maximum output frequency
320 Hz
Maximum output voltage
400 V
Mains voltage from
380 V
Carrier frequency
0.5…16
Rated output current
110 A
MODBUS protocol support
Yes
With control unit
Yes
With built-in braking resistors
Yes
With PC connection
No
IP protection rating
IP20
Cooling type: air cooling, water cooling
Fan (built-in)
AC frequency converter type
Direct converter
Mains frequency
50/60 Hz
Width
235 mm
