ONI (Группа IEK)
Frequency converter FC-431 380V 3Ph 5.5-7.5kW 13-17A built-in braking module ONI FC-431-33-055G075PT
SKU: FC-431-33-055G075PT
ETIM: EC001857
214,254 ₽
Get back 2,142 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 6 шт
Analogues by specifications
Stock by warehouse
No description available
Input current HD constant load mode
15
Input current, ND variable load mode
20
Height
235 mm
Height
235 mm
Output power at rated output voltage
7.50 kW
Output current, HD mode constant load
13.0
ND mode output current at variable load
17.0
Depth
160 mm
Electric shock protection class
I
Number of input phases
3
Number of output phases
3
Number of phases
3
Max. motor power in HD constant load mode
5.5
Max. motor power in ND variable load mode
7.5
Maximum output power at linear load at rated output voltage
5.5 kW
Maximum output frequency
320 Hz
Maximum output voltage
400 V
Mains voltage from
380 V
Carrier frequency
0.5…16
Rated output current
17 A
MODBUS protocol support
Yes
With control unit
Yes
With built-in braking resistors
Yes
With PC connection
No
IP protection rating
IP20
Cooling type: air cooling, water cooling
Fan (built-in)
AC frequency converter type
Direct converter
Mains frequency
50/60 Hz
Width
143 mm
