ONI (Группа IEK)
Frequency converter K751 380V 3Ph 22-30kW 45-60A with built-in brake and DC choke ONI K751-33-2230TRM
SKU: K751-33-2230TRM
ETIM: EC001857
245,752 ₽
Get back 2,457 ₽ in points
Analogues by specifications
Frequency inverter for general industrial and heavy-duty applications with vector feedback, Modbus RTU/TCP support, and expansion boards (industrial protocols, I/O board, encoder/resolver).
The primary purpose is to control the operation of lifts and crane mechanisms. It has proven itself excellent in residential, commercial construction, and various industrial sectors. Due to the presence of a large number of built-in protections, the service life of the electric motor is significantly extended.
Weight
9.8 кг
Input current HD constant load mode
46.5
Input current, ND variable load mode
62
Height
370 мм
Height
370 мм
Output power at rated output voltage
22.00 кВт
Output frequency
0...600
Output current, HD mode constant load
45.0
ND mode output current at variable load
60.0
Depth
195 мм
Mechanical design group
M2
Operating input voltage range
Please provide the full text or product data you would like me to translate. Currently, you have only provided a numerical range "323...483".
Permitted for use in industrial areas
Yes
Electric shock protection class
It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.
Climatic version
UKhL3.1
Number of HW serial RS-485 interfaces
1
Number of input phases
3
Number of output phases
3
Number of phases
3
Max. motor power in HD constant load mode
22
Max. motor power in ND variable load mode
30
Maximum output power at linear load at rated output voltage
22 кВт
Maximum output frequency
600 Гц
Maximum output voltage
483 В
Maximum supply cable cross-section
16 кв.мм
Output voltage from
0...483 В
Mains voltage from
400 В
Carrier frequency
1...8
Rated output voltage
400 В
Rated output current
60.0 А
AS-Interface Safety at Work protocol support
No
ASI protocol support
No
CAN protocol support
No
Data Highway protocol support
No
DeviceNet protocol support
No
DeviceNet Safety protocol support
No
Ethernet / IP protocol support
No
Foundation Fieldbus protocol support
No
INTERBUS protocol support
No
KNX protocol support
No
LON protocol support
No
MODBUS protocol support
Yes
PROFIBUS protocol support
No
PROFINET CBA protocol support
No
PROFINET IO protocol support
No
PROFIsafe protocol support
No
SUCONET protocol support
No
SafetyBUS p protocol support
No
TCP/IP protocol support
No
Protocol support for INTERBUS Safety
No
SERCOS protocol support
No
With control unit
Yes
With built-in braking resistors
Yes
With PC connection
Yes
IP protection rating
IP20
Operating temperature from
-10...40 град.C
Cooling type: air cooling, water cooling
Fan (built-in)
AC frequency converter type
Other
Mains frequency
50/60 Hz
Width
210 мм
