Ladder tray vertical external corner 45deg. 100x150x1.5mm "Quick installation" HD85 KM LO58609 KM SYSTEM
SKU: LO58609
ETIM: EC001535
8050 ₽
Preorder
Vertical external ladder angle 45 degrees "Quick installation" is used to change the direction of the cable route during installation. Such a bend prevents damage to the cable route during installation. It is recommended to use this element with a metal ladder tray with a width of 150 mm and a side height of 100 mm. The product is hot-dip galvanized according to GOST 9.307-2021 and is used for installation in rooms with high humidity and low pollution, outdoors, and in low-corrosive environments, in accordance with GOST 15150-69. Connection between sections is made using suitable fasteners. For additional protection of the cable route element from dust and debris, use a cover.
| Material type/grade | Galvanized steel |
| Internal radius | 300 мм |
| Cable ladder height | 100 мм |
| Protective surface coating | Hot-dip galvanizing |
| Direction change | Vertically down |
| Design | With built-in integrated connector |
| Material | Steel |
| Perforated side wall | No |
| Rotation (angle) | 45 deg. |
| Side profile type | Profile (open) |
| Step type | Perforated profile |
| Color | Light grey |
| Hinged fastening | No |
| Ladder-type cable tray width | 150 мм |
