No description available
Special power supply
No special power supply required
RAL number (similar)
9 010
Antibacterial
No
Wireless local area network
No
Material type/grade
Thermoplastic
Device height
86 мм
Device depth
45 мм
Differential current protection
No
For heavy duty (per VDE)
No
Contact protection
Yes
Overvoltage protection
No
Protective surface coating
Untreated
Round protective grounding contact (pin)
Yes
Insulated installation
Yes
Design
With earthing contact
Number of seats
1
Number of switchable outlets
1
Number of phases
1
Material
Plastic
Extraction mechanism
No
Minimum depth of recessed mounting box
45 мм
Halogen-free
Yes
Rated voltage
230 В
Rated current
16 А
Support ring
Yes
Labelling surface
No
Suitable for ingress protection IP
IP44
Transparent
No
With built-in USB charger
No
With power switch
No
With lock
No
With orientation lighting
No
With hinged cover
Yes
With illumination (mains voltage indication)
No
With signal lamp
No
With low-current fuse
No
With through-channel function
No
With central insert
No
Symbols/indication
Without marking/printing
With shutters (touch protection)
Yes
Mounting method
Internal / concealed
Connection method
Screw clamp/terminal
Configuration type
Assembled with housing/frame
Fastening type
By expansion (tabs) and screws
Surface type
Glossy
Impact resistance
IK01
Colour
White
Color
White
Frequency at
60 Гц
Frequency from
50...60 Гц
Device width
86 мм
