Generica (Группа IEK)
Twisted pair U/UTP 5E 24AWG 2PR PVC 1m grey 100m Russia GENERICA BC1-C5E02-111-100-R-G
SKU: BC1-C5E02-111-100-R-G
ETIM: EC003249
2,000 ₽
Get back 20 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 100 м
Analogues by specifications
Stock by warehouse
No description available
Cable outer diameter
5.0±0.1
Wave impedance
100 Ом
Conductor diameter
0.46 мм
Cable length
100 м
For laying in the ground
No
Permissible operating temperature (no movement) to
60 град.C
Permissible operating temperature (without movement) from
-20...60 град.C
NVP value
69 %
Core insulation
Solid polyethylene
Category
5E
Conductor class
Class 1 (solid conductor)
Reaction to fire class in accordance with EN 13501-6
O1.8.2.5.4
Number of cores
4
Number of twisted elements
2
Max mutual capacitance per 100 metres
5.6
Max. contact resistance
20
Max. capacitance unbalance pF per 100 m
160
Max DC resistance per 100m at 20°C, not more than
9.5
Cable/wire grade
U/UTP
Core marking
Colour
Outer sheath material
PVC
Conductor material
Copper
Mounting temperature from
-10...50 град.C
Outer diameter (approx.)
5.0 мм
Low smoke emission in accordance with EN 61034-2 (ng-LS version)
No
Rated transmission rate
69
Rated voltage from
≤ 48 В
Rated conductor cross-section
0.166 кв.мм
With metal cable
No
Halogen-free (per IEC 60754-2)
No
Core cross-section
24 мм
Insulation resistance
5000
Operating temperature from
-20...60 град.C
Twist type
Lay (layer)
UV resistance
No
Outer sheath colour
Grey
Signal frequency
100
Screen over the twist
No
Screen over stranding element
No
Dielectric strength
1000
Twisting element
Paired
