IEK
Circuit breaker VA88-35 3P 160A 35kA MASTER IEK SVA30-3-0160-02
SKU: SVA30-3-0160-02
ETIM: EC000228
8,559 ₽
Get back 85 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 6 шт
From our own stock you can buy 1 шт in any quantity. Above that — supply on order, in multiples of 6 шт.
Analogues by specifications
Stock by warehouse
VA88 MASTER molded case circuit breaker is designed to protect electrical networks from short-circuit currents, overload currents, unacceptable voltage drops, as well as for conducting current in normal mode.
Circuit breakers are manufactured in 5 frame sizes, equipped with a thermomagnetic release for currents from 16 to 800A and an electronic release for currents from 125 to 800A. Operating voltage 400/690 V.
The design of the circuit breaker allows for the independent installation of additional devices at the customer's site.
Built-in ground fault protection
No
Built-in motor drive
No
Height
165.2 mm
Height
165.2 mm
Altitude above sea level
< 2000
Depth
97.8 mm
Setting range of overload protection device from
160 A
Instantaneous short-circuit release setting range from
1600 A
Design
Stationary
Climatic version
UKhL3
Number of auxiliary NO contacts
0
Number of auxiliary changeover contacts
0
Number of auxiliary break contacts
0
Number of poles
3
Design
Other
Motor drive optional
Yes
Electronic release available
No
Rated impulse withstand voltage
8
Rated service short-circuit breaking capacity Ics
18.75
Rated ultimate short-circuit breaking capacity Icu at 400 V, 50 Hz
25 kA
Rated voltage
400...690 V
Rated insulation voltage Ui
800 V
Rated voltage up to
690 V
Rated voltage from
400...690 V
Rated current
160 A
Rated continuous current Iu
160 A
Suitable for DIN-rail mounting
No
Power loss
50 W
Operating mode
Continuous
With minimum voltage protection
Yes
Tripping system
Thermal, electromagnetic
IP protection rating
IP20
Terminal ingress protection IP
IP00
Operating temperature from
-40...60 °C
Product/component type
Moulded case circuit breaker
Main electrical circuit connection type
Screw connection
Control element type
Toggle switch
Mains supply frequency
50 Hz
Width
107.0 mm
