Residual current circuit breaker 2P (1P+N) C 25A 300mA type AC 4.5kA АД-32 electronic protection 230V PRO D32E2C25AC300P Эра Б0057374

SKU: Б0057374 ETIM: EC000905

1,144 ₽

Get back 11 ₽ in points

Description Specifications Reviews

Mounting installation depth 71 мм

For flush mounting Yes

False tripping protection No

Number of protected poles 1

Rated breaking capacity per IEC 60947-2 6 кА

Rated short-circuit breaking capacity Icn per EN 61009-1 4.5 кА

Rated short-circuit breaking capacity per EN 61009 4.5 кА

Rated voltage 230 В

Rated current 25 А

Rated leakage current It appears your message contains only ".3". Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly. мА

Total number of poles 2

Ambient operating temperature to 50 град.C

Ambient operating temperature from -25 град.C

Current type Alternating current (AC)

With switched neutral conductor Yes

With interlock device No

Flexible stranded conductor cross-section up to 25 кв.мм

Stranded flexible conductor cross-section from 1 кв.мм

Solid conductor cross-section to 25 кв.мм

Solid conductor cross-section from 1 кв.мм

Pollution degree (number) 2

IP protection rating IP20

Residual current type Alternating current (AC)

Tripping characteristic Without time delay

Tripping characteristic It seems your message was cut off. Please provide the text you would like me to translate from Russian to English, and I will follow your instructions strictly.

Frequency (Hz) 50 Hz

Width in modular units 2
