Residual current circuit breaker 2p (1P+N) C 6A 30mA type A 6kA Systeme9 230V SE S9D56606 Systeme Electric
SKU: S9D56606
ETIM: EC000905
5,868 ₽
Get back 58 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Stock by warehouse
No description available
Mounting installation depth
45 мм
Number of protected poles
1
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
4 кВ
Rated voltage
230 В
Rated insulation voltage Ui
500 В
Rated current
6 А
Rated leakage current
.03 мА
Total number of poles
2
Ambient operating temperature to
60 град.C
Ambient operating temperature from
-25 град.C
Current type
Alternating current (AC)
With switched neutral conductor
Yes
Flexible stranded conductor cross-section up to
16 кв.мм
Stranded flexible conductor cross-section from
16 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Residual current type
A
Tripping characteristic
Without time delay
Tripping characteristic
C
Frequency (Hz)
50/60 Hz
Width in modular units
2
