Residual current circuit breaker 2p (1P+N) C 6A 30mA type AC 6kA RX3 IEK Leg 419396 Legrand (IEK group)
SKU: 419396
ETIM: EC000905
24,084 ₽
Get back 240 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Order multiple: 6 шт
Analogues by specifications
Stock by warehouse
No description available
Mounting installation depth
50 мм
For flush mounting
No
False tripping protection
No
Overvoltage protection
No
Overvoltage category
2
Protection class per GOST IEC 61140
0
Current limiting class
3
Climatic version
UKhL3.1
Number of protected poles
1
Number of poles
8
Maximum supply cable cross-section
16 кв.мм
Mechanical durability
20000
Tightening torque of contact terminal screws
2
Availability of residual current release
Yes
Thermal release available
Yes
Electromagnetic release present
Yes
Electronic release available
No
Rated impulse withstand voltage
10
Rated non-tripping residual current
36
Rated differential making and breaking capacity
1500
Rated breaking capacity in accordance with EN 60898
6 кА
Rated breaking capacity per IEC 60947-2
6 кА
Rated short-circuit breaking capacity Icn per EN 61009-1
6 кА
Rated impulse voltage
4 кВ
Rated voltage
236 В
Rated insulation voltage Ui
500 В
Rated current
6 А
Rated leakage current
0.03 мА
Total number of poles
2
Breaking capacity per IEC 61009-1
6000
Ambient operating temperature to
60 град.C
Ambient operating temperature from
-25 град.C
Operating mode
Continuous
Breaking capacity
6.0 кА
Current type
Alternating current (AC)
With switched neutral conductor
Yes
With interlock device
No
Flexible stranded conductor cross-section up to
10 кв.мм
Stranded flexible conductor cross-section from
.75 кв.мм
Solid conductor cross-section to
16 кв.мм
Solid conductor cross-section from
.75 кв.мм
Tripping system
Thermal, electromagnetic
Mounting method
On DIN rail
Pollution degree (number)
2
IP protection rating
IP20
Operating temperature
-25...70
Residual current type
Alternating current (AC)
Connection type
Screw connection
Tripping characteristic
C
Frequency (Hz)
50/60 Hz
Width in modular units
8
Electrical wear resistance
10000
