DKC
Modular circuit breaker YON MD63 3P 16A C 10kA MD63-3C16-10 DKC
SKU: MD63-3C16-10
ETIM: EC000042
2,665 ₽
Get back 26 ₽ in points
Promo code
FIRST
— cashback ×3 on your first order: 3% in points on the first 50,000 ₽
Analogues by specifications
Modular three-pole circuit breaker YON MD63 rated 16 A with trip characteristic "C" and breaking capacity 10 kA is designed for use in electrical circuits with voltage up to 400 V AC at a frequency of 50 Hz, for their protection against overloads and short circuits, for carrying current in normal mode and for rapid switching on and off of said circuits. An independent release in a separate module and auxiliary contacts in a separate module can be attached to the circuit breaker. The independent release and auxiliary contacts are ordered separately and installed on the circuit breakers by the consumer as needed.
Additional equipment possible
Yes
Mounting installation depth
69.9 мм
For flush mounting
No
Number of protected poles
3
Rated short-circuit breaking capacity Icu IEC 60898 at 230 V
10 кА
Rated short-circuit breaking capacity Icu IEC 60898 at 400 V
10 кА
Rated breaking capacity in accordance with EN 60898
10 кА
Rated impulse voltage
4 кВ
Rated voltage
400 В
Rated insulation voltage Ui
400 В
Rated current
16 А
Total number of poles
3
Ambient operating temperature to
30 град.C
Ambient operating temperature from
30 град.C
Current type
Alternating current (AC)
With switched neutral conductor
No
Flexible stranded conductor cross-section up to
25 кв.мм
Stranded flexible conductor cross-section from
25 кв.мм
Solid conductor cross-section to
25 кв.мм
Solid conductor cross-section from
25 кв.мм
Pollution degree (number)
3
IP protection rating
IP20
Tripping characteristic
C
Frequency
50 Гц
Frequency at
50 Гц
Frequency from
50 Гц
Width in modular units
3
0
★★★★★
0 reviews
No reviews yet. Be the first!
Leave a review
Related products
367 ₽
Generica (Группа IEK) Circuit breaker VA47-29M 2P 50A 4.5kA C GENERICA MVA21-2-050-C-G
SKU: MVA21-2-050-C-G
205 ₽
EKF Circuit breaker VA 47-63N 1P 20A (V) 4.5 kA PROXIMA EKF M634120B
SKU: M634120B
397 ₽
IEK ARMAT Circuit Breaker M10N 1P D 25A IEK AR-M10N-1-D025
